VK-BCL-2C Automatic Carton Box Double Corner Wrap Tamper-Evident Labeling Machine
$8,200.00
Tax included. Shipping calculated at checkout.
VK-BCL-2C Corner wrap labeler is suitable for corner labeling for various carton box products. Adapt inline continuous labeling without product pause. Which is most suitable tamper-evident & corner labeling product within the market.
Output Speed: 40-150 pieces/minute depends on label and product size
Dimension: (L)2800*(W)1200*(H)1500(mm)
View Video Download PDF
Description
Corner wrap labeler is suitable for corner labeling for various carton box products. Adapt inline continuous labeling without product pause. Which is most suitable tamper-evident & corner labeling product within the market.
Well-designed structure efficiently adjusts applicator position and related assembly, complicated part changeover is not required. Through touch screen will able to proceed detail and specific settings.
General labels, transparent labels, or other tamper-evident labels can be applied.
Application
Drawing
Paramenters
| Model | VK-BCL-2C |
| Labeling Speed(pcs/min) | 40-150(relate to product and label size) |
| Labeling Accuracy(mm) | ±1.0mm |
| Suitable Label Size(mm) | (L)20-300mm (H)15-100mm(Customizable) |
| Suitable Box Size | No Limit(Customizable) |
| Roll Inside Diameter(mm) | Φ76mm |
| Rollouter Diameter(mm) | Φ320mm |
| Machine Size(mm) | (L)2800*(W)1200*(H)1500(mm) |
| Power Supply | AC220V 50Hz/60Hz (Customizable) |
| Operation Direction | Left To Right Or Right To Left |
| Net Weight | About 320Kg |
| Label Material | Self-Adhesive Sticker, Opaque Or Transparent Label |
Details
VK-BCL-2C Touch Screen
The touch screen control panel, which serves as the interface for operating the labeling machine. With its intuitive layout, operators can easily configure settings, monitor performance, and troubleshoot issues. The emergency stop button adds an essential safety feature, while the advanced display technology ensures a user-friendly experience.
VK-BCL-2C Conveyor Belt
The conveyor belt ensures the smooth, continuous transport of products during the labeling process. Its modular design provides stability and efficient movement, reducing downtime and improving alignment for precise labeling.
VK-BCL-2C Label Peeling Knife
The label peeling knife facilitates the separation of adhesive labels from their backing paper. Its sharp and precise edge enhances label application accuracy, ensuring consistent performance and reducing wastage.
VK-BCL-2C Label Sensor
The label sensor detects the presence and position of labels for accurate placement on products. This component improves labeling precision, supports automation, and ensures synchronization with the machine’s operational speed.
VK-BCL-2C Labeling Head
The labeling head handles the precise application of labels onto products, ensuring accurate placement and alignment. The modular design allows for easy adjustments and maintenance, enhancing operational flexibility. Additionally, the robust construction ensures durability and reliability in high-speed operations.
VK-BCL-2C Top Pressure Belt Mechanism
The top pressure belt mechanism, designed to stabilize products as they move along the conveyor during the labeling process. This mechanism prevents slippage or misalignment, ensuring consistent labeling accuracy. Its adjustable settings accommodate different product sizes and shapes, making it versatile for various applications.
Features
It is complied with GMP standard that provides easy maintenance and for a long durable life.
The mobility castor and stainless-steel fixing nut are designed to flexibly move the machinery to support another production line to boost the invest benefits.
It provides a wide range adjustment ability by equipped with hand wheel mechanism for easy adjustment of applicator and depended on products.
Smart label length set to quickly achieve for perfect position of label by counter.
Missing label set prevents product miss-labeled to ensure product accuracy while production and fulfill production QC procedure.
A built-in counter can either run freely keeping track of the number of products labeled to control the production.
Production preset function that the labeler automatically stops when the desired numbers of products have been labeled for efficient production management.
Auto label start up mode while the power been switch on, the machine will enter labeling condition automatically as previous run without reset.
Labeling delay function that it is ideal for small scale adjustment and could do calculate digitally for dispensing speed and position.
